Solenoid Valves

Information

Specifications
  • These are high performance valves and solenoid valves for fast operations.
  • Number of ways (Position) available: 3/2-way NC and NO; 5/2-way and 5/3-way CC, CO, CP.
  • Actuation method: Double solenoid; Single solenoid and spring return;
Pneumatic-pneumatic or Pneumatic and spring.
  • Materials: Aluminium body, Stainless steel spool and NBR seals.
  • Mounting: Through 2 Ø5 holes in the valve body.
  • Number of Ports: NAMUR – 2 and 4; G1/4 – 1, 3 and 5.
  • Installation: Directly on a Namur Interface.
  • Wide range of solenoid voltage available.
  • Operating pressure:
    • 5 – 10 bar double solenoid.
    • 5 – 10 bar single solenoid.
  • Nominal pressure: up to 6 bar.
  • Nominal flow (Qn): up to 1000 Nl/min
  • Nominal diameter: 8 mm.
  • Fluid: Filtered air without lubrication.
  • The solenoid valves can also be equipped with solenoids
that are in compliance with UL or ATEX standards.
